Model

A Model is a catalog resource that wraps the configuration needed to connect to a large language model (LLM) provider. It decouples the LLM choice from the agents that use it: agents reference a model by name, so swapping the underlying model (or updating API credentials) requires changing only the Model resource without touching any Agent.

.

Model reference

Field	Required	Description
Title	Yes	Display name shown in the UI and in the agent creation form's model picker.
Name	Yes	Unique identifier, auto-derived from Title. Lowercase letters, digits, dots, and hyphens only (must start and end with an alphanumeric character), max 63 characters. Immutable after creation. Must match the value used in Agent.spec.model.
Description	Yes	Short description of the model's capabilities or intended use.
Tags	No	Free-form, multi-value tags used to make the model easier to find and filter.
Type	Yes	The LiteLLM model identifier string passed directly to the runtime, e.g. gpt-4o, vertex_ai/gemini-pro, anthropic/claude-sonnet-5.
Provider	Yes	Free-text, human-readable provider label (e.g. OpenAI, Anthropic, Google). Currently informational only — not yet rendered in any AI Foundry UI view.
Secret	No	Name of the environment variable that holds the API key. The key is never stored in the catalog; only its variable name is.
URL	No	Free-text reference URL for the model endpoint. Currently informational only — the runtime ignores this field and does not use it to route requests.
Context Window	No	Maximum context window size in tokens. Informational; surfaced in the model detail view.
Supports Tools	No	Set to true if the model supports tool/function calling. Used by the AI Playground to determine which agent features are available. Defaults to true.
Supports Vision	No	Set to true if the model accepts image inputs. Defaults to false.
LiteLLM	No	Explicit override for whether requests are routed through LiteLLM. The runtime already enables LiteLLM automatically for any model that has a Type value set (i.e. essentially always, since Type is required) — use this field only to force it off.
Arguments	No	A free-form JSON object with default parameters applied to every request (e.g. temperature, max_tokens, top_p). Individual agents can override these via Agent.spec.model_arguments.

See also

• Agent: resources that reference a model.
